ASSMANN Digitus ASSNET250 Cat.6 U/UTP installation cable, 305 m, Eca
Digitus ASSNET250 Cat.6 U/UTP installation cable, 305 m, Eca, 305 m, Cat6, U/UTP (UTP)
ACU-4611-305
4016032317197
€99.90
VAT included
Description
Digitus ASSNET250 Cat.6 U/UTP installation cable, 305 m, Eca. Cable length: 305 m, Cable standard: Cat6, Cable shielding: U/UTP (UTP)
- Physical properties:
- Conductor: Copper covered aluminum, solid AWG 23/1
- Insulation: HD-PE (High Density Polyethylene)
- Total number of insulated conductors: 8, twisted in 4 pairs
- Color code: Blue-white, orange-white, green-white, brown-white
- Individual pair shield: None
- Overall shielding: None
- Outer sheat: Eca acc. to EN 50575; PVC
- Outer sheath diameter (nominal): 0,55 mm nominal
- Outer sheath color: Grey (RAL 7035)
- Mechanical properties:
- Tensile loading: 150N max.
- Dynamic bending radius: 8x AD mm min.
- Static bending radius: 4x AD mm min.
- Shipping- and storage temperature range: -20 °C up to +75 °C
- Operating temperature range: -20 °C up to +60 °C
- Installation temperature range: 0 °C up to +50 °C
- Electrical properties:
- Impedance: 100±15 Ohm @ 1-100 MHz
- Capacitance: 40 pF/m nominal @ 800 Hz
- Capacitance unbalance (pair-ground): 1.5 pF/m max. @ 1 KHz
- Insulation resistance: 2 GOhm x km min.
- DC loop resistance: 262 Ohm/km max. (2% max. resistance unbalance)
- Voltage resistance: 72 Vdc max.
- Coupling attenuation: CA-Type 3
- Signal propagation delay: 535 nS/100 m max.
- Propagation delay: 20 nS/100 m max.
- Separating class: ,,b" acc. to EN 50174-2
- Maximum operating length: 60 m
- NVP: 69%
Data sheet
- Colour
- Black
- Garantie
- 2 ans
- Marque
- Assmann
- Modèle
- ACU-4611-305
- Weight
- 1
Specific References
- ean13
- 4016032317197
