PLANET PLANET IPOE-E302 network extender Network transmitter Black, Grey 10, 100, 1000 Mbit/s

PLANET IPOE-E302, Network transmitter, 10,100,1000 Mbit/s, Full, Half, 2000 entries, IP67, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x
4711605284929
4711605284929
€204.90
VAT included

Visa
Mastercard
PayPal

Description

PLANET IPOE-E302. Type: Network transmitter, Ethernet LAN data rates: 10,100,1000 Mbit/s, Duplex system: Full, Half. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x. Product colour: Black, Grey, LED indicators: Activity, Link, Certification: FCC 15 A, CE IEC 60068-2-32, IEC 60068-2-27, IEC 60068-2-6. Power consumption (max): 97 W, Total Power over Ethernet (PoE) budget: 65 W. Width: 150 mm, Depth: 43.8 mm, Height: 72.9 mm
  • Physical Port
  • Three 10/100/1000BASE-T Gigabit RJ45 ports
  • 1-port data power input
  • 2-port data power output
  • Power over Ethernet
  • Complies with IEEE 802.3bt PoE Type 4 standard PD
  • Compatible with PoH (Power over HDBASE-T) protocol
  • Backward compatible with IEEE 802.3at PoE end-span or mid-span PD
  • Supports PoE input power up to 95 watts
  • Complies with IEEE 802.3at Power over Ethernet mid-span PSE
  • Up to 2 IEEE 802.3af/802.3at PoE devices powered
  • Supports total PoE budget up to 65 watts for 2 PoE output ports
  • Auto detects powered device (PD)
  • Extends the range of PoE to an additional 100 meters (328ft.)
  • Forwards both Ethernet data and PoE power to remote device
  • Layer 2 Features
  • Hardware-based 10/100Mbps, half / full duplex and 1000Mbps full duplex mode, flow control, auto-negotiation and auto MDI/MDI-X
  • Features Store-and-Forward mode with wire-speed filtering and forwarding rates
  • IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation
  • Integrates address look-up engine, supporting 2K absolute MAC addresses
  • 9K jumbo frame support in 1000Mbps duplex mode
  • Automatic address learning and address aging
  • Industrial Case and Installation
  • IP67-rated aluminum case
  • Wall-mount design
  • Supports 6KV DC Ethernet ESD protection
  • 40 to 75 degrees C operating temperature
  • No external power cable required for installation
  • Plug and Play installation

Data sheet

Colour
Black
Garantie
2 ans
Marque
PLANET

Specific References

ean13
4711605284929
