PLANET Technology Corp.po PLANET WGS-5225-8T2SV network switch Managed L2+ Gigabit Ethernet (10/100/1000) Black

PLANET WGS-5225-8T2SV, Managed, L2+, Gigabit Ethernet (10/100/1000), Full duplex, Wall mountable
WGS-5225-8T2SV
4711605283519
€499.90
VAT included

Visa
Mastercard
PayPal

Description

PLANET WGS-5225-8T2SV. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 8000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE.... DC input voltage: 12 - 48 V. Power connector: Terminal block (3-pin). Wall mountable
  • Physical Port
  • 8 10/100/1000BASE-T Gigabit Ethernet RJ45 ports
  • 2 100/1000/2500BASE-X mini-GBIC/SFP slots for SFP type auto detection
  • Industrial Case and Installation
  • Compact size with fixed wall-mounted, magnetic wall-mounted or DIN-rail design
  • IP30 metal case
  • Supports -20 to 70 degrees C operating temperature
  • Supports ESD 6KV DC Ethernet protection
  • Redundant power input design
  • 12V~48V DC wide power input with polarity reverse protect function
  • 3-pin terminal block or DC jack connector
  • Layer 2 Features
  • Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control (full-duplex)
  • High performance of Store-and-Forward architecture, and runt/CRC filtering eliminates erroneous packets to optimize the network bandwidth
  • Storm Control support
  • Broadcast/Multicast/Unicast
  • Supports VLAN
  • IEEE 802.1Q tagged VLAN
  • Up to 255 VLANs groups, out of 4094 VLAN IDs
  • Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)
  • Private VLAN Edge (PVE)
  • Protocol-based VLAN
  • MAC-based VLAN- Voice VLAN
  • Supports Spanning Tree Protocol
  • IEEE 802.1D Spanning Tree Protocol (STP)
  • IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
  • IEEE 802.1s Multiple Spanning Tree Protocol (MSTP), spanning tree by VLAN- BPDU Guard
  • Supports Link Aggregation
  • 802.3ad Link Aggregation Control Protocol (LACP)
  • Cisco ether-channel (static trunk)
  • Maximum 5 trunk groups with 2 ports per trunk group
  • Up to 2Gbps bandwidth (duplex mode)
  • Provides port mirror (1-to-1)
  • Port mirroring to monitor the incoming or outgoing traffic on a particular port
  • Loop protection to avoid broadcast loops
  • Supports ERPS (Ethernet Ring Protection Switching)
  • Layer 3 IP Routing Features
  • Supports maximum 32 static routes and route summarization

Data sheet

Colour
Black
Garantie
2 ans
Marque
PLANET Technology Corp.po

Specific References

ean13
4711605283519
