Aten ATEN VE2812EUT AV extender AV transmitter White
ATEN VE2812EUT, 4096 x 2160 pixels, AV transmitter, 150 m, Wired, White, HDCP
VE2812AEUT-AT-G
4719264647383
€493.90
VAT included
Description
ATEN VE2812EUT. Type: AV transmitter, Maximum resolution: 4096 x 2160 pixels, Cable types supported: Cat5e, Cat6, Cat6a. Connectivity technology: Wired. Power consumption (transmitter) (max): 3.14 W. Width: 108 mm, Depth: 50 mm, Height: 51.7 mm
- Extends HDMI or VGA signals over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable
- Designed to mount in a two-gang junction box
- HDMI 1.4 (3D, Deep color, 4K); HDCP 2.2 compliant
- Superior video quality:
- • HDMI: 4K at distance up to 100 m via a Cat 6a or ATEN 2L-2910 Cat 6 cable
- • VGA: 1600 x 1200 and 1920 x 1200 up to 100 m via a Cat 6a or ATEN 2L-2910 Cat 6 cable
- Supports HDBaseT Long Reach Mode – up to 150 m via a single Cat 5e/6 cable at resolutions up to 1080p
- Supports Auto Switch – automatically switches to a newly plugged-in source
- Functions as a switch or a converter
- • A Switch: Connects two sources (HDMI or VGA)
- • A Converter: Applies receivers with different interface (DVI, DisplayPort, or HDMI)
- Supports RS-232 channel transmission or command mode for source switch control
- Compatible Receivers – VE1812R, VE812R, VE814AR, VE811R, VE801R, VE802R, VE601R, VE901R or future ATEN HDBaseT Receivers
- Plug-and-play
- Built- in 8KV / 15 KV ESD protection
- LED indication of sources and device status
Data sheet
- Colour
- Black
- Garantie
- 2 ans
- Marque
- Aten
Specific References
- ean13
- 4719264647383
